SCROLL TECH ST-R125 KE-TFD-3PH-460V-60HZ-R407
Scroll Compressor (≈ 10 HP / ~125,000 BTU class, industrial voltage version)
This is the TFD high-voltage variant of the ScrollTech ST-R125 series, designed for commercial HVAC and chiller applications using R407C refrigerant and operating on 3-phase 460V / 60Hz power.
It is in the same performance class as Copeland ZR125KCE-TFD-950 scroll compressors, which are widely used in North American and industrial HVAC systems.
Key Specifications (ST-R125 TFD version)
- Brand: ScrollTech
- Model: ST-R125 KE-TFD
- Compressor type: Hermetic scroll
- Refrigerant: R407C (also compatible with R22/R134a in equivalent designs)
- Power supply: 3-Phase, 460V / 60Hz
- Capacity: ~125,000 BTU/h (≈ 10 HP class)
- Oil type: POE oil
- Application: Commercial AC / rooftop units / small chillers
Electrical / Design Notes
- “TFD” = high-voltage scroll motor configuration (380–420V / 460V class family)
- Built-in internal motor protection
- Requires external contactor + overload relay
- No capacitor (3-phase direct drive)
- Designed for continuous commercial duty
Equivalent Industry Reference
This compressor is closely aligned with:
- Copeland ZR125KCE-TFD-950
- Cooling capacity: ~125,000 BTU (≈ 27 kW range)
-
Typical suction/discharge:
- Suction: 1-3/8”
- Discharge: 7/8”
Typical Applications
- 10 ton commercial split systems
- Rooftop packaged air conditioners
- Small air-cooled chillers
- Large VRF fixed-speed compressor circuits
Key Features
- High efficiency scroll design
- Low vibration and noise
- Stable performance under heavy load
- POE oil system for R407C
- Industrial-grade 460V operation
