SCROLL TECH ST-R72 KE-TF5-3PH-220V60HZ-R407 SCROLL TECH COMPRESSOR
Inhouse product
-
105.00
-
1,748.00
1,788.25
SCROLL TECH ST-R72 KE-TF5-3PH-220V-60HZ-R407
Scroll Compressor (6 HP class, HVAC/R use)
This is a ScrollTech hermetic scroll compressor from the ST-R series, designed for air-conditioning and refrigeration systems using R407C refrigerant (also compatible with similar HFC blends depending on application design).
From the manufacturer technical data, the ST-R72 series is part of the 6 HP class scroll lineup.
Key Specifications (Model Interpretation)
- Brand: ScrollTech
- Series: ST-R72 (Air Conditioning series)
- Refrigerant: R407C
- Power Supply: 3 Phase, 220V, 60Hz
- Nominal Capacity: ~17.5–20 kW class (≈ 60,000–72,000 BTU/h depending conditions)
- Compressor Type: Hermetic scroll
- Application: Air conditioning / chiller / heat pump systems
Technical Highlights (ST-R72 range)
- Displacement: ~17.2 m³/h (ST-R72 class)
- Refrigerants supported (series-based): R22 / R407C / R410A (variant dependent)
- Motor type: 3-phase induction motor (TF5 version = 220–230V class variants in similar scroll families)
- Oil type: POE oil (typical for R407C systems)
- Application range: comfort cooling, commercial HVAC, chillers
Pipe Connection (important for installation)
Typical suction/discharge for this class (based on ST-R72 family data):
- Suction line: ~1-3/8”
- Discharge line: ~7/8”
Matching System Use
- Split AC outdoor units (6–6.5 ton class)
- Rooftop units
- Small chillers
- VRF auxiliary circuits (non-inverter fixed speed setups)
Important Notes
- “TF5-3PH-220V-60HZ” indicates a low-voltage 3-phase motor variant
- Must use correct contactor + overload protection
- Must ensure R407C POE oil compatibility
- Proper superheat/subcooling setup is critical for scroll life
Quick comparison (real-world equivalent)
This model is generally comparable to:
- Copeland ZR72 / ZR72KC series (6 HP class) in capacity and application range
